The gum slitting machine is a specialized core equipment for the production of gum base confectionery, primarily utilizing ultrasonic cutting technology, specifically designed for highly adhesive and stick-prone materials like gum. It converts high-frequency electrical signals into mechanical micro-vibrations at tens of thousands of times per second, achieving a "non-sticking blade" low-heat cutting effect. This effectively avoids issues such as blade adhesion, stringing at the cut, and dimensional deviations common with traditional cutting blades.
Mainstream models often integrate extrusion molding and cutting processes, enabling seamless connection from base material extrusion to finished product cutting without secondary positioning. This ensures clean, uniform cuts while reducing material waste and equipment cleaning downtime. Additionally, parameters such as extrusion speed and cutter head amplitude can be flexibly adjusted to meet the production requirements of various gum specifications, significantly improving production line automation efficiency and product consistency.
|
Main motor |
1.5kW-2 PC, 90W-1 PC (380V, 50Hz) |
|
Machine hood |
304 stainless steel |
|
Machine frame |
Channel steel and Q235 welded assembly |
|
Control appliances |
Schneider |
|
Inverter |
Wei Chuang |
|
Conveyor belt |
FDA approved food grade belt |
|
External dimensions |
L1350×W1180×H1400mm |
|
Weight |
≈500 KG |
|
Total power |
3.5KW |
1. The cross-cut and longitudinal-cut functions operate independently with adjustable speed settings. The length and width of the gum pieces can be customized according to requirements, meeting product personalization needs;
2. Precision Cutting. The cutting is performed with high accuracy according to system settings, featuring sharp blades that resist wear and produce no burrs after cutting;
3. Scrap recycling. Equipped with a recycling conveyor belt, it can automatically collect scrap materials and return them to the extruder, reducing material loss
4. Food-grade conveyor belts. The use of food-grade conveyor belts ensures the hygiene and safety of food
Why Choose Zhonghong Slitting Machine?
1 Our company has over 20 years of experience in producing bubble gum chewing gum equipment, which can solve the problems that arise during the production of bubble gum chewing gum
2 Our slitting machine is hygienic and safe, ensuring that candy materials meet food safety production standards
3 Our slitting machine has high production efficiency and low failure rate, ensuring continuous production
4 Our machines have a one-year quality warranty period, and the company provides technical personnel for customer training
Application & Final Products
A.Dual-axis independent speed control with zero dimensional accuracy error
Equipped with an advanced independent control system, the transverse and longitudinal cutting stations can be independently adjusted for operating speed, eliminating the linkage deviation common in traditional equipment where "adjusting one affects all." The length and width dimensions of each piece of gum are consistently controlled within a 0.1mm tolerance, ensuring no defects such as uneven lengths or widths, achieving perfect consistency in finished product specifications.
B. Precision speed control eliminates burrs, directly upgrading the finished product's quality
Through dynamic speed matching of horizontal and vertical cutting, the issues of burrs and stringing caused by blade pulling are completely eliminated. The gum cutting edges are smooth and even, eliminating the need for additional manual secondary trimming. This directly skips a post-processing step, resulting in a product appearance that far exceeds industry standards.
C. Automatic conveyance and recycling of edge scraps, achieving zero material loss, leakage, overflow, or waste
The scrap generated from slitting is automatically collected and transported via dedicated conveyor belts, eliminating the need for manual cleaning and collection throughout the process. This not only prevents sugar dust from scattering in the workshop, which could attract pests and contaminate the production environment, but also enables centralized closed-loop recycling of the scrap. As a result, material utilization rates are further improved, leading to significant savings in raw material costs over long-term production.
D.The operational threshold has been significantly lowered, allowing beginners to get started quickly
The control system has been scenario-optimized and simplified, eliminating the need for complex professional debugging expertise. With just one hour of basic training, ordinary operators can independently complete the entire process of parameter settings and model switching. This eliminates the need to hire highly paid senior maintenance personnel, directly reducing factory labor recruitment and training costs.
FAQ
Q1:Are you a factory or trading company?
A1:We are an industry and trade integrated factory, located in Foshan,since 2005.
Q2:What is your delivery time?
A2:It takes about 90 days.
Q3:Can i have my own specific requirment product?
A3:Yes, we can make it according your request.
Q4:How do you control your product quality?
A4:We have experienced technicians to test the products before send them out.
Q5:What is your warranty?
A5:The Quality Guaranty period is 12 months from the date of SAT，but no more than 14 months after shipping date.
Q6:Can the production line be integrated with automated packaging equipment?
A6:Yes, it supports integration with pillow packaging machines, vertical packaging machines, bottling machines, etc., and can also be paired with metal detectors and weight checking machines to achieve full-process automation.
Q7:How to start the bubble gum production?
A7:You can send inquiry to us, we will give you the advises.
